CRRC Permanent Magnet Synchronous Generator Wind Turbine
CRRC permanent magnet synchronous generator (PMSG) product portfolio covers three technical routes: large-capacity offshore semi-direct drive, compact integrated semi-direct drive and low-speed full direct drive, with rated power ranging from 1.5 MW to 7.6 MW. The product line is applicable to inland onshore wind farms, coastal salt-fog zones and harsh offshore marine operating environments.
Semi-direct drive models adopt optimized matching with medium-speed gearboxes, compact dual cooling structures and integrated bearing layout to cut nacelle space occupation, reduce overall system weight and maintenance workload; direct drive units connect directly with wheel hubs, eliminating gearboxes to simplify transmission chains, lower mechanical loss and improve long-term operational reliability. All models work with full-power PWM converters to deliver high-quality grid electricity, featuring outstanding low voltage ride-through capability and grid adaptability. Customized cooling, anti-corrosion and low-temperature reinforcement options are available to satisfy diverse wind farm construction demands across different regions.
General Specifications of CRRC Permanent Magnet Synchronous Generator Wind Turbine Series
| Rated Power: | 1580 – 7600 kW |
| Rated Voltage: | 690 – 720 V |
| Rated Current: | 720 – 3347 A |
| Rated rotating speed: |
12.2 – 550 rpm |
| Insulation Class: |
F / H |
| Rated Frequency: |
50 Hz |
| Rated Efficiency: | ≥97% ~ 98% |
| Power Factor: | 0.9 – 0.95cap |
| Protection Class: | IP23 / IP54 |
| Weight: | 12 – 69 t |
| 2.5MW2560 kW | ||||||||
| 3.3MW3400 kW | ||||||||
| 4.2MW4200 kW | ||||||||
| 6.25MW6400 kW | ||||||||
|
Product Model Rated output power/kW |
0 | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | 7000 |
Product Model |
Rated output power |
Rated voltage |
Product Model |
Rated output power |
Rated voltage |
||
| 2.5MW Generator | 2500 kW | 690 V | 3.3MW Generator | 3300 kW | 690 V | ||
| 4.2MW Generator | 4200 kW | 1140 V | 6.25MW Generator | 6400 kW | 1140 V | ||
| ——END—— | |||||||
Permanent Magnet Synchronous Generator Wind Turbine Series
CRRC 1.5MW Direct-Drive PMSG
Rated Power: 1580 kW
Rated Voltage: 720 V
Rated Rotating Speed: 16.6 – 20.5 rpm
Rated Current: 720 A
Weight: 44 t
CRRC 2MW Direct-Drive PMSG
Rated Power: 2120 kW
Rated Voltage: 720 V
Rated Rotating Speed: 14 rpm
Rated Current: 2×1006 A
Weight: 49 t
CRRC 2.5MW Direct-Drive PMSG
Rated Power: 2650 kW
Rated Voltage: 690 V
Rated Rotating Speed: 13.5 – 16 rpm
Rated Current: 2×1394 A
Weight: 53 t
CRRC 3MW Direct-Drive PMSG
Rated Power: 3350 kW
Rated Voltage: 690 V
Rated Rotating Speed: 12.2 – 13.9 rpm
Rated Current: 2×1800 A
Weight: 69 t
CRRC 3MW Integrated Semi-Direct Drive PMSG
Rated Power: 3200 / 3400 / 3620 kW
Rated Voltage: 710 V
Rated Rotating Speed: 480 / 526 / 550 rpm
Rated Current: N/A
Weight: 12 t
CRRC 3.6MW Semi-Direct Drive PMSG
Rated Power: 3830 kW
Rated Voltage: 690 V
Rated Rotating Speed: 350 rpm
Rated Current: N/A
Weight: 17.5 t
CRRC 7.6MW Semi-Direct Drive PMSG
Rated Power: 7600 kW
Rated Voltage: 690 V
Rated Rotating Speed: 278 rpm
Rated Current: 3347 A
Weight: 48.5 t
