CRRC Construction Motors

CRRC construction motors series is a family of robust, high-performance drive solutions engineered specifically for heavy-duty construction machinery and equipment. The series of motors ranges in rated power from 290 kW to 360 kW and offers dual rated power options (continuous/1 hour) to meet the needs of stable and peak loads.
These motors feature advanced designs, including dual H/H insulation systems, shunt excitation technology, and high-efficiency ventilation, ensuring reliable performance in harsh construction environments with dust, vibration, and wide temperature fluctuations. With rated voltages of 558 V to 1500 V and speeds up to 2000 rpm, they are fully compatible with mainstream construction equipment systems, providing stable traction and power output for excavators, cranes, and tunneling machinery.
Built on CRRC’s mature high-speed rail motor manufacturing technology, the series delivers high energy efficiency (up to 91%) and low long-term operating costs, making it ideal for large-scale infrastructure projects and heavy construction applications.
If you are in need of a motor model that is not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and technical documents available here at CRRC.

coming soon

coming soon

General Specifications of CRRC Construction Motors Series

Rated Power: 290 – 360 kW
Rated Voltage: 558 – 1500 V
Rated Current:
205 – 710 A
Rated Speed:
820 – 880 rpm
Insulation Grade:
H/H
CDZD108 CDZD1081500 V
ZD126G ZD126G558 V

Motor Model

Rated voltage/V

300 500 700 900 1100 1300 1500 1700
CRRC Construction Motors Catalogue

Motor Model

Rated output power

Rated Voltage

Motor Model

Rated output power

Rated Voltage

CDZD108 290/350 kW 1500 V ZD126G 360kW 558 V
——END——

Construction Series Motors

This is the list of all series of CRRC Construction Series Motors.
Click here to find construction motors by type
CRRC CDZD108 Traction Motor

CRRC CDZD108 Traction Motor

Rated output power: 290/350 kW
Rated voltage: 1500 V
Rated current: 205/250 A
Rated rotating speed: 880/820 rpm

CRRC ZD126G Series Motors

CRRC ZD126G Series Motors

Rated output power: 360kW
Rated voltage: 558 V
Rated current: 710 A
Rated rotating speed: 835 rpm
